We customize according to your needs, and can be combined. One device of network interface filters can be customized with six network interfaces.
Contact usProduct Introduction
Interface Classification：DB9\DB25\BNC\HDMI\USB\RJ45\VGA\TNC；
Product identification
Interface Filter Selection Table
| Model | Interface Type | Rated Current（A） | Rated Voltage（V） | Operating Frequency（Hz） | Number of Interfaces | Climatic Category | SE(Hz) | SE |
| FS-DB9-JK | 串口 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-DB9-JK2 | 串口 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-V8-JK | 百兆网络 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-V8-JK2 | 百兆网络 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-KWY-JK | 千兆网络 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-KWY-JK2 | 千兆网络 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-USB2.0-JK | USB2.0 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-USB2.0-JK2 | USB2.0 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-USB3.0-JK | USB3.0 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-HDMI-JK | 视频信号 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-VGA-JK | 视频信号 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-DB25-JK | 串口 | 2 | 50VDC | / | 1 | 25/70/25 | 0.45-10GHz | 70dB |
| FS-FT1B-JK | 电源 | 10 | 110/250VAC | 50/60Hz | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-BNC5-JK2 | BNC50Ω | 5 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-BNC7-JK2 | BNC75Ω | 5 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
Interface Filter Dimension Table
| Model | Drawing No. | Size | ||||||||||
| A | B | C | D | E | F | H | Q | K | L | J | ||
| FS-DB9-JK |  | 152 | 110 | 60 | 84 | 75 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-DB9-JK2 |  | 152 | 110 | 82 | 84 | 75 | 70 | 58 | 22 | 100 | 50 | 4.2 |
| FS-V8-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-V8-JK2 |  | 152 | 110 | 82 | 84 | 75 | 70 | 58 | 22 | 100 | 50 | 4.2 |
| FS-KWY-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-KWY-JK2 |  | 152 | 110 | 82 | 84 | 75 | 70 | 58 | 22 | 100 | 50 | 4.2 |
| FS-USB2.0-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-USB2.0-JK2 |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-USB3.0-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-HDMI-JK |  | 162 | 110 | 82 | 84 | 80 | 70 | 58 | / | 100 | 50 | 4.2 |
| FS-VGA-JK |  | 162 | 110 | 82 | 84 | 80 | 70 | 58 | / | 100 | 50 | 4.2 |
| FS-DB25-JK |  | 152 | 125 | 60 | 95 | 75 | 50 | 30 | / | 115 | 65 | 3.5 |
| FS-FT1B-JK |  | 130 | 102 | 66 | 75 | 64 | 55 | 43 | / | 90 | 50 | 3.5 |
| FS-BNC5-JK2 |  | 112 | 85 | 60 | 55 | 55 | 45 | 30 | / | 70 | 35 | 4.2 |
| FS-BNC7-JK2 |  | 112 | 85 | 60 | 55 | 55 | 45 | 30 | / | 70 | 35 | 4.2 |
